Jata VIN145 - Function Details, Maintenance, and Environment; Maximum Power Function; Troubleshooting Error Codes; Maintenance and Cleaning

13
Maximum power function:
• Inthisfunctionyoucansettheoperatingtime,butyoucannotadjustthetemperature,sinceitisxed.
• Press“Preset tiempo”.Thedisplaywillstartblinking.
• Press“+or-”toadjust.
• Once the time has been set, it will be xed in a few seconds. The display will stop blinking.
• Youcanstoptheoperationbypressing“Pausa”.
• Toresume,pressagain.
• Itmustbetakenintoaccountthatthedevicewillautomaticallyswitchoafterpassingthetimeshowninthe
displayoncepressed“Pausa”.
• Toturnotheunitpress anddisconnectitfromthenetwork.
• Ifanerrorcodeappearsonthedisplay,refertothetable:
Trouble code Possible Reasons Solutions
E0 -Nopot/panontheplate;
-Non-usablePansontheplate.
-DiameterofPotissmallerthan120mm.
Putsuitablecookingutensilsontheplate.
E1 -IGBTElectrocircuitmulfunction.
-IGBTsensorisinopencircuitorinshort
circuit.
Pleasecontactthesupplierorgotoa
qualiedservicecenter.
E2 -Temperaturesensorfailure(inopencircuit
orinshortcircuit).
Pleasecontactthesupplierorgotoa
qualiedservicecenter.
e3 -Abnormalsupplyvoltage:voltagetoolow
(<80V).
Pleasecheckpowersupply,poweronafter
powersupplyisbacktonormal.
e4 -Abnormalsupplyvoltage:voltagetoo
high(>280V).
Pleasecheckpowersupply,poweronafter
powersupplyisbacktonormal.
e6 -Platesurfacetemperaturetoohigh.
-Emptypot/panheatingleadstotoohigh
temperature.
Pleasewaitforsomeminutesuntilthecools
down.
Pleasecheckpot/pan.
E7 -Thermalresistordoesn’twork. Pleasecontactthesupplierorgotoa
qualiedservicecenter.
-WhenE3orE4appears,devicewillautomaticallystopheatingbutdonotshutdown.
-WhenotherTroubleCodeappear,devicewillautomaticallystopheatingandshutdown.
Youcouldpress

functiontorestartthedeviceandeliminatetheTroubleCode.
MAINTENANCE AND CLEANING
• Beforeyouproceedtocleaning,unplugtheappliancefromthemainsandwaituntiltheplateistotallycold.
• Youcancleanthebodywithaslightlydampenedcloth.
• Tocleantheplateitisenoughtouseaslightlydampenedclothwithsoap.Youalsocancleantheplatewith
specialproductstocleanvitroceramicplates.
• Iftherearesomehardresiduesyoucanuseascrapersuitableforvitroceramichobs.
• Donotuseabrasiveorchemicalproducts,metallicscourers,andsuchmaydeterioratethesurfaces.
ENVIRONMENT PROTECTION
• Disposetheapplianceaccordingtothelocalgarbageregulations.
• Neverthrowitawaytotherubbish.Soyouwillhelptotheimprovementoftheenvironment.
