E.P. -GAS CONSUMPTION
Most gas appliances are only operated intermittently. Unless there
is heavy use of hot water, water heater consumption is not too
great. During freezing weather and high wind conditions, furnace
consumption can be extremely
heavy.
I,.P.-gas consumption depends upon individual use of appliances
and
the length of time operated.
Each gallon of I,.P.-gas produces
about 91,500 BTU's of heat energy. Follouing is a list of typical
appliance consuniptior! when turned
full on for one hour of
operation:
AVERAGE BTU
APPLIANCE CONSUMPTION PER HOUR
Stove: Burner Tog - Each 5,200
Oven Burzer - Each 7,100
Heater (Opt .)
12,000 - 16.000
Refrigerator: RM220 1 (Opt) 600
RM2 190 (0~1.) 565
RM230 1 (Opt.) 1 000
Water Heater (Deluxe Only) 9,000
Note: The above is an example of a typical system and may not represent
the exaci system in your particular unit.
USING THE AUTOMATILC CHANGEOVER REGULATOR
(For Optional Double Bottles Only)
A useful accessory is an automatic change over regillam. This
apparatus allows both
gas batties to be turned on simultaneously.
The arrow on the regulator handle indicates ~vhich bottle is in
service. When the indicated bottle in service becomes empty,
changeover is autornaticaily accomplished hi tomnwncc drakving
fuei from $he other bottle. At this point, thc plastic tvindois will
display a red signal or- tlag to indicate thc condition. You should
thcn flip thc !ever over to indicate sct.i.ii.e on tho othi'r boltle. The
first bottlo \vliich was deplcrcd can ;hen be turned off, ~incouplcd
and taken :u be refilled ~ithont distirrbitig $13~ K.V. gas supply.
After rcfiiiing. ir c:rt7 he rernotintcd and agnirl turned to the "On"
position. Whcn the other bottle is depleted. the E.P.-gas suppl!:
ivill again be nutomaticaliy changcd wcr.
ELECTRICAL SYSTEM & OPERATION
Your eIectrical system of 120-volts AC and 12 vuits DC has been
designed and installed in accordance with the safety requirements
