SECTION 3 – PRE-TRAVEL INFORMATION JAYCO TOWABLE TABLE OF CONTENTS
3-4
Loading the ramps
The RV is equipped with folding ramps to load equipment onto the front deck. These
ramps are secured to the front deck to create a railing during travel.
1. Unlock and remove one ramp from the front deck and place it on the edge you will be
using to load the front deck.
2. Secure the ramp for loading by attaching one end of the tie down to the unit frame,
and the other tie down end to the ramp. Repeat for the other ramp.
3. After loading your equipment onto the front deck, reverse these steps and secure the
ramps for travel.
Front deck and
loading ramps
Loading the front deck
It is important for your safety, and for the proper handling of the camping trailer, that the
following guidelines are followed when loading the front deck.
(1) Load all cargo evenly from front to back and side to side on the cargo deck.
(2) Secure all cargo to prevent the load from shifting during travel.
(3) Weigh the trailer at the hitch, each axle and wheel.
(4) Observe all Gross Vehicle Weight (GVWR), Gross Axle (GAWR), and Tire Ratings
listed on the certification label located on the lower front of the left sidewall.
WARNING
It is important that the loading ramps and any equipment on the front deck is secured
before travel. Failure to properly secure items to the front deck could lead to property
damage and personal injury.
WARNING
1400 lb. (635 kg) distributed load capacity per pair/700 lb. (318 kg) distributed load
capacity each ramp. Do not ride vehicle on ramps. Chains & straps must be
secured to limit ramp movement. Use as a loading ramp only. Ramp surface is
slippery when wet. Do not stop between rungs. If ramp is bowing while loading,
remove load immediately. Keep body parts clear of hinge pinch areas. Use on level
and stable surfaces only. Failure to follow instructions may result in serious injury.
