JAYCO TOWABLE SECTION 6 – ELECTRICAL SYSTEM
6-3
Always test the external power source (i.e., the campsite power receptacle or electrical
box) with a ground monitor before connecting your power cord to it. If the ground monitor
indicates 'reverse polarity' or an 'open ground' DO NOT connect the power cord.
1. Turn “off” the load center main 120-volt circuit breaker.
2. Carefully extend the entire length of the power cord (approximately 25’-35’) from the
electric cable hatch to the external power source.
3. Plug the power cord into the receptacle. Be sure all the power cord prongs are
properly plugged into the receptacle.
4. Return to your recreation vehicle and turn “on” the load center main circuit breaker.
5. To help prevent power surges from damaging the connected loads, please follow
these instructions when hooking up to the external power source:
The shore line power cord should be unplugged when the recreation vehicle is left
unattended. If something would happen to the electrical system, this may help limit
potential damage.
When you are ready to leave, reverse the power cord connection process. Use care to
prevent damaging the power cord electrical connection pins when connecting or
disconnecting the shore line power cord. Grasp the plug to remove the power cord from the
outlet; do not unplug it by pulling on the cord.
Maintenance
Inspect the power cord for cuts, cracks and worn insulation. Have the power cord replaced
immediately if these symptoms are noticed.
120-VOLT (30 AMP) AC SYSTEM (IF SO EQUIPPED)
Your recreation vehicle may be equipped with a 30 amp 120-volt 60hz AC electrical
system. The entire system is designed to operate on 1 leg of 120-volt power at a maximum
current flow of 30 amperes. Depending on your model, the 30 Amp input will look like
one of the two examples shown here.
Exposure to voltages higher or lower than a nominal 120-volts will damage or shorten the
service life of the electrical system and appliances. The 30 amp 120-volt 60hz AC
electrical system can be powered by the 120-volt 60hz utilities found in RV campgrounds
or by 120-volt 60hz generator power.
The following electrical components will only operate when your motorhome is connected
to shore or generator power: 120 to 12-volt power converter, air conditioner, refrigerator,
microwave oven, television(s), home theater system(s), electric water heater, washer,
dryer, fireplace, and appliances plugged into convenience receptacles.
