JAYCO TOWABLE SECTION 6 – ELECTRICAL SYSTEM
6-11
NOTE: Command center configurations and components may vary from model to
model. Not all components listed may be available in your model.
Command Center Panel:
Items found on this panel typically include (may vary by model):
 Fuel gauge and hour meter with switches for fuel pump and fuel levels
 Lighted red pump switch, lighted red water heater switches (electric & LP gas)
 Generator start / stop switch
 Tank heater switches
 Light switches for porch lights, exterior security lights, interior lights, awning LED
lights, front cap LED accent lights
 Cargo bed red lighted master control switch
 Slideout control switches (press and hold to extend / retract)
 Awning control switches (press and hold to extend / retract)
Command Center Panel with Switch Modules:
Items may include separate switch modules and controls that are mounted to a recessed
plastic panel. Items found on this panel typically include (may vary by model):
 Systems monitor with LED indicators for tank levels and battery charge status
 Systems monitor includes lighted red switches for pump and water heater
 Slideout switches (press and hold to retract / extend slideouts)
 Light switches for porch lights, exterior security lights, interior lights, awning LED
lights, power entry step
 Awning switches (press and hold to retract / extend awning)
 Auto leveling control panel (for leveling the recreation vehicle)
 Inverter panel (power switch with display)
 Generator start / stop control with hour meter
 Cargo bed red lighted master control switch
 Power bunk bed lift control switch
 Fuel gauge with fuel station on/off switch
 Speaker selector switch
Command Center Modules Mounted to the Wall
Some models may have the modules mounted directly to the interior wall of the vehicle.
They are typically located near the entrance door. They may include any of the modules
listed above.
