OPERATION
1. Connect the phone plug cable; one end to the jack of Audio
out, another end to the Mic mixing jack of Karaoke Amplifier,
audio mixer, etc...
2. Please set the same frequency which is not interfered in local
area for receiver and microphone.
3. The squelch level is adjustable by the squelch adjustment at
the back of the unit, adjust the output level to prevent from
the external noise. (Setting the squelch to high will reduce
the range of the system).
4. When the receiver is not used, remove the power supply.
1 .......... Power Switch
2 .......... Channel Selector
3 .......... Power Indicator
4 .......... Diversity AB Indicator
5 .......... Volume Control
6 .......... Antenna B
7 .......... Balanced Output
8 .......... Unbalanced Output
9 .......... Squelch Adjustment
10 ........ DC Socket
11 ........ Antenna A
6
MR-SU9 + UT-16A + UF-16A
