Service Notes
The 5231 and 5232 utilize integrated circuitry. Proper opera-
tion can be verified by measurement of DC output voltages for
each integrated circuit which should measure 0, ±Vi VDC. If
this specification is not met, the integrated circuit is defective
and should be replaced.
DC voltages are measured with respect to ground. It should
be noted that a DC voltmeter having a high input impedance
(10 megohms or greater) is recommended.
