JBL A/B Studio S38II - Page 2

Screws (6)
#8 x .75" HXS-HD
903802-012
Screws (4)
#6 x .75" PPH
63563
Screws (2)
PPH H/L 6-19 x 5/8 Znc
905402-010
Network
335410-003
Port Tube (2)
337775-001
Woofer
335149-002
Grille Retainers (4)
333249-001
Terminal Cup
335471-002
Enclosure
S38II (not for sale)
Binding-
Post Nuts (2)
T879-01
Faceplate
Gasket
338077-001
Screws (6)
#6 x .75" HXS-HD
908302-012
Faceplate
A: 337776-002
B: 337776-001
Grille
338038-001
Tweeter
338042-001
Bar, Hold Down
338059-001
A
B
Flower Pot
334072-001
Screws (4)
#6 x .75"
PPH 63563
Midrange
338040-001
Screw (4)
#6 x .75" PPH
61867
S38II
(A/B) Studio
™
Series
S38II (A/B) Studio
™
Series
07/02
JBL Consumer Products, 250 Crossways Park Dr., Woodbury, New York 11797
EXPLODED VIEW
