JBL Control Control One Pro - Key Features and Mounting Guide; Key Features; Bracket Assembly and Mounting

71
(2.8)
52
(2.1)
32
(1.3)
57
(2.3)
61
(2.4)
142
(5.6)
235
(9.3)
235
(9.3)
159
(6.3)
CONTROL 1 PRO
PROFESSIONAL
JBL Professional
8500 Balboa Boulevard, P.O. Box 2200
Northridge, California 91329 U.S.A.
© Copyright 2006 JBL Professional
A Harman International Company
SS C1P
CRP 5M
08/06
䉴 Control 1 Pro Two-Way Professional Compact Loudspeaker
20 100 1000 10000 20000
Frequency (Hz)
10
100
360
-6 dB Beamwidth (degrees)
Horizontal
Vertical
Frequency Response:
Beamwidth:
Dimensions:
20 100 1000 10000 20000
Frequency (Hz)
0
10
20
1
10
100
Directivity Index (DI), dB
Directivity Factor (Q)
Horizontal Off-Axis Frequency Response:
Directivity Index:
20 100 1000 10000 20000
Frequency (Hz)
-30
-20
-10
0
10
Attenuation (dB)
0 deg
10 deg
20 deg
30 deg
40 deg
50 deg
60 deg
70 deg
80 deg
Mounting Bracket:
Dimensions in mm (in)
