JBL CS100 User Manual

CS100 120v Electrical parts List
Part Number Description Qty
Reference Designato
Input/Preamp PCB
Resistors
110-16102j26-e Resistor 1K 1/6W ±5% CF 26mm (RoHS) 5
R213,R214,R215,R254,R253
110-16103j26-e Resistor 10K 1/6W ±5% CF 26mm (RoHS) 17
R212,R216,R217,R220,R221,R222,R225,R226,
R227,R228,
R229,R230,R232,R240,R260,R235,R200
110-16104j26-e Resistor 100K 1/6W ±5% CF 26mm (RoHS) 3
R231,R263,R266
,
110-16105j26-e Resistor 1M 1/6W ±5% CF 26mm (RoHS) 1
R259,
110-16122j26-e Resistor 1.2K 1/6W ±5% CF 26mm (RoHS) 1
R265,
110-16124j26-e Resistor 120K 1/6W ±5% CF 26mm (RoHS) 1
R233,
110-16153j26-e Resistor 15K 1/6W ±5% CF 26mm (RoHS) 1
R234,
110-16183j26-e Resistor 18K 1/6W ±5% CF 26mm (RoHS) 1
R262,
110-16205j26-e Resistor 2M 1/6W ±5% CF 26mm (RoHS) 1
R257,
110-16223j26-e Resistor 22K 1/6W ±5% CF 26mm (RoHS) 3
R238,R255,R256
,
110-16224j26-e Resistor 220K 1/6W ±5% CF 26mm (RoHS) 1
R251,
110-16273j26-e Resistor 27K 1/6W ±5% CF 26mm (RoHS) 2
R223,R237,
110-16472j26-e Resistor 4.7K 1/6W ±5% CF 26mm (RoHS) 3
R258,R210,R209
,
110-16473j26-e Resistor 47K 1/6W ±5% CF 26mm (RoHS) 4
R219,R249,R250,R264
,
110-16474j26-e Resistor 470K 1/6W ±5% CF 26mm (RoHS) 1
R252,
110-16512j26-e Resistor 5.1K 1/6W ±5% CF 26mm (RoHS) 1
R211,
110-16513j26-e Resistor 51K 1/6W ±5% CF 26mm (RoHS) 1
R224,
115-h503a102-e VAR Resistor RV16AE-20B2-15K-A54-104(A50K) LEVEL 1
VR201,
Capacitors
129-a154j633-e Metalize CAP. 0.15U 63V ±5% MSC (RoHS) 2
C221,C222,
130-2b221k503-e Disc capacitor 220P 50V ±10% (RoHS) 9
C207,C208,C210,C211,C212,C214,C220,C230
C249,
130-3f104z503-e Disc capacitor 0.1U 50V +80/-20% (RoHS) 8
C232,C242,C244,C245,C246,C252,C254,C256,
130-ch220k503-e Disc capacitor 22PF CH 50V±10% (RoHS) 1
C229,
132-103j503-e Mylar capacitor 0.01uF 50V ±5% (RoHS) 2
C223,C224,
132-104ja03-e Mylar capacitor 0.1UF 100V ±5% (RoHS) 1
C218,
132-223ja03-e Mylar capacitor 0.022uF 100V ±5% (RoHS) 1
C215,
132-473ja03-e Mylar capacitor 0.047uF 100V ±5% (RoHS) 2
C216,C217,
135-3105m50-e Electroytic CAP. 1U 50V ±20% (RoHS) 1
C228,
135-3106m50-e Electroytic CAP. 10uF 50V ±20% (RoHS) 8
C206,C213,C219,C231,C241,C243,C251,C253,
135-3107m16-e Electroytic CAP. 100uF 16V ±20% (RoHS) 1
C234,
135-3226m50-e Electroytic CAP. 22U 50V ±20% (RoHS) 2
C505,C506,
135-3227m16-e Electroytic CAP. 220U 16V ±20% (RoHS) 1
C118,
Semiconductors
192-027c1815gr-e Transistor 2SC1815GR TOSHIBA(RoHS) NPN 3
Q206,Q207,Q208
,
197-631n4148-e Diode 500mW 75V 1N4148 Panjit (RoHS) 9
D201,D202,D207,D208,D211,D212,D214,D21
5
D216,
199-65000513g-e zen Diode GDZJ5.1B 500mW 5.1V 2% 26mm 1N5231B(RoHS) 1
D213,
190-06m4558d-e
I.C. OPA 4558D (RoHS) DUAL OP-AMP
1
U203,
190-16tl074cn-e
*I.C TL074CN ST (RoHS) QUAD OP-AMP
2
U201,U202,
195-10204hgw-e dual color LED 204HGW (RoHS) 1
D209,
Miscellaneous
174-0rca108gv-e RCA-108GV purple JK203 (RoHS) 1
JK201,
174-0rcb202vag-e RCA JACK RCA-209 gild (RoHS) 1
JK202,
175-1c07v01-e Wire connector & base 7PIN PITCH=2.5mm (RoHS) 1
M201,
180-tms7210v-e SWITCH SLIDE 6PIN MS7210V (RoHS) 1
SW202,
362-FE-00041-0LAE PCB bracket 11.75*8.5*12.5H (RoHS) 1
CS100 (CS6100 Subwoofer)

JBL CS100 Specifications

General

Brand	JBL
Model	CS100
Category	Subwoofer
Language	English
