Part Number Description Qty
Reference Designato
Main Amp PCB
Resistors
110-14103j26-e Resistor 10K 1/4W ±5% CF 26mm (RoHS) 3
R503,R504,R510
110-14222j26-e Resistor 2.2K 1/4W ±5% CF 26mm (RoHS) 1
R511
110-14432j26-e Resistor 4.3K 1/4W ±5% CF 26mm (RoHS) 1
R506,
110-14472j26-e Resistor 4.7K 1/4W ±5% CF 26mm (RoHS) 1
R505,
110-16102j26-e Resistor 1K 1/6W ±5% CF 26mm (RoHS) 1
R153,
110-16103j26-e Resistor 10K 1/6W ±5% CF 26mm (RoHS) 10
R128,R130,R149,R150,R305,R306,R308,R311
R314,R319,
110-16104j26-e Resistor 100K 1/6W ±5% CF 26mm (RoHS) 3
R122,R126,R307
110-16153j26-e Resistor 15K 1/6W ±5% CF 26mm (RoHS) 1
R107,
110-16182j26-e Resistor 1.8K 1/6W ±5% CF 26mm (RoHS) 1
R145,
110-16203j26-e Resistor 20K 1/6W ±5% CF 26mm (RoHS) 1
R309,
110-16221j26-e Resistor 220Ω 1/6W ±5% CF 26mm (RoHS) 1
R144,
110-16222j26-e Resistor 2.2K 1/6W ±5% CF 26mm (RoHS) 1
R102,
110-16223j26-e Resistor 22K 1/6W ±5% CF 26mm (RoHS) 1
R316,
110-16333j26-e Resistor 33K 1/6W ±5% CF 26mm (RoHS) 1
R310,
110-16393j26-e Resistor 39K 1/6W ±5% CF 26mm (RoHS) 1
R151,
110-16473j26-e Resistor 47K 1/6W ±5% CF 26mm (RoHS) 2
R106,R129,
110-16474j26-e Resistor 470K 1/6W ±5% CF 26mm (RoHS) 2
R127,R312,
110-16562j26-e Resistor 5.6K 1/6W ±5% CF 26mm (RoHS) 1
R152,
110-16621j26-e Resistor 620Ω 1/6W ±5% CF 26mm (RoHS) 1
R160,
110-16751j26-e Resistor 750Ω 1/6W ±5% CF 26mm (RoHS) 1
R315,
110-16755j26-e Resistor 7.5M 1/6W ±5% CF 26mm (RoHS) 1
R313,
116-161002f26-e Metal film Resistor 10K 1/6W ±1% MF 26mm (RoHS) 2
R301,R303,
116-161102f26-e Metal film Resistor 11.0K 1/6W ±1% MF 26mm (RoHS) 1
R302,
116-162200f26-e Metal film Resistor 220Ω 1/6W ±1% MF 26mm (RoHS) 1
R317,
116-162202f26-e Metal film Resistor 22.0K 1/6W ±1% MF 26mm (RoHS) 1
R318,
110-20332jk3-e Resistor 3.3K 2W ±5% standing short feet 7.5m(RoHS) 1
R134,
113-50s68j00-e cement Resistor 0.068Ω 5W ±5% horizontal (RoHS) 1
R147,
116-201001jk3x-e oxidation foil Resistor 1.00K 2W ±5% standing 7.5mm (RoHS) 1
R148,
116-304700jk2x-e oxidation foil Resistor 470Ω 3W ±5% clip feet 10mm (RoHS) 2
R501,R502,
Capacitors
130-3f104z503-e Disc capacitor 0.1U 50V +80/-20% (RoHS) 6
C107,C117,C122,C144,C320,C322
130-sl101k503-e Disc capacitor 100P 50V SL ±10% (RoHS) 3
C302,C303,C306
132-103j503-e Mylar capacitor 0.01uF 50V ±5% (RoHS) 2
C305,C317,
132-103ja03-e Mylar capacitor 0.01uf 100V ±5% (RoHS) 2
C103,C104,
132-104ja03-e Mylar capacitor 0.1UF 100V ±5% (RoHS) 3
C123,C503,C504
132-273ja03-e Mylar capacitor 0.027UF 100V ±5% (RoHS) 1
C143,
135-3106m50-e Electroytic CAP. 10uF 50V ±20% (RoHS) 2
C319,C321,
135-3107m10-e Electroytic CAP. 100U 10V ±20% (RoHS) 2
C114,C115,
135-3107m35-e Electroytic CAP. 100U 35V ±20% (RoHS) 2
C507,C508,
135-3225m50-e Electroytic CAP. 2.2U 50V ±20% (RoHS) 1
C509,
135-3226m16-e Electroytic CAP. 22U 16V ±20% (RoHS) 1
C304,
135-3226m50-e Electroytic CAP. 22U 50V ±20% (RoHS) 2
C505,C506,
135-3227m16-e Electroytic CAP. 220U 16V ±20% (RoHS) 1
C118,
135-3476m16-e Electroytic CAP. 47U 16V ±20% (RoHS) 1
C318,
132-103kd00-e Mylar capacitor 0.01U 400V +/-10% long feet (RoHS) 1
C500,
135-4478m63-e Electroytic CAP. 4700uF 63V ±20% (RoHS) 2
C501,C502,
130-3f104z503-e Disc capacitor 0.1U 50V +80/-20% (RoHS) 1
C110,
Semiconductors
190-16tl074cn-e
I.C TL074CN ST (RoHS) QUAD OP-AMP
1
U301,
192-161tip31c-e
Transistor TIP31C SGS (RoHS) NPN
1
Q501,
192-162tip32c-e
TransistorTIP32C SGS (RoHS) PNP
1
Q502,
197-00kbu606g-e
diode6A 800V KBU606G (RoHS) BRIDGE
1
D501,
197-141n4004-e Diode 1N4004 molding short feet (RoHS) 2
D110,D504,
192-027c1815gr-e
Transistor 2SC1815GR TOSHIBA(RoHS) NPN
5
Q108,Q109,Q113,Q301,Q302
CS100 (CS6100 Subwoofer)
