JBL CS100 User Manual

Part Number Description Qty
Reference Designato
Main Amp PCB
192-027c2235y-e
Transistor 2SC2235Y TOSHIBA (RoHS) NPN
1
Q111,
192-028a1015gr-e
Transistor 2SA1015GR TOSHIBA(RoHS) PNP
3
Q101,Q107,Q112
,
192-1572n5551-e
Transistor FSC 2N5551 (RoHS) NPN
2
Q114,Q115,
192-1582n5401-e
Transistor FSC 2N5401 TO-92 (RoHS) PNP
1
Q503,
197-631n4148-e Diode 500mW 75V 1N4148 Panjit (RoHS) 7
D102,D103,D104,D105,D143,D301,D302
199-65000623g-e zener Diode GDZJ6.2B 500mW 6.2V 26mm 2% (RoHS) 1
D101,
199-65001603g-e zener Diode GDZJ16C 500mW 16V 26mm 2% (RoHS) 1
D502,
Miscellaneous
175-1d02v01-e Wire connector & base 2PIN PITCH=3.96mm (RoHS) 1
M100,
175-1d03v01-e
Wire connector & base 3 PIN PITCH=3.96mm JST-VH no middle PIN
1
M500,
362-FE-00013-0LAE PCB bracket L TYPE t=1.6mm S.P.C.C 89*9*1.6T (RoHS) 2
Class D amp PCB (Replacment of entire module is recommended, part# 051-B00012A-E).
Resistors
118-12061001j-e SMD Resistor 1.00K 1206 5% (RoHS) 7
R2,R11,R29,R30,R7,R9,R25
,
118-12061002j-e SMD Resistor 10.0K 1206 5% (RoHS) 3
R7.R9.R25
118-120610r0j-e SMD Resistor 10.0Ω 1206 5% (RoHS) 2
R22,R23,
118-12061201j-e SMD Resistor 1.20K 1206 5% (RoHS) 16
R31,R32,R33,R34,R35,R36,R37,R38,R39,R40
R41, R42,R43,R44,R45,R46,
118-12062002j-e SMD Resistor 20.0K 1206 5% (RoHS) 1
R26,
118-12062201j-e SMD Resistor 2.20K 1206 5% (RoHS) 3
R6,R13,R16,
118-12062701j-e SMD Resistor 2.70K 1206 5% (RoHS) 1
R10,
118-12063000j-e SMD Resistor 300.0Ω 1206 5% (RoHS) 1
R24,
118-12063301j-e SMD Resistor 3.30K 1206 5% (RoHS) 4
R14,R15,R27,R28
,
118-12063902j-e SMD Resistor 39.0K 1206 5% (RoHS) 1
R3,
118-12064700j-e SMD Resistor 470Ω 1206 5% (RoHS) 1
R8,
118-12064701j-e SMD Resistor 4.70K 1206 5% (RoHS) 3
R1,R5,R12,
118-12064702j-e SMD Resistor 47.0K 1206 5% (RoHS) 1
R17,
118-12064704j-e SMD Resistor 4.70M 1206 5% (RoHS) 1
R4,
118-120647r0j-e SMD Resistor 47.0Ω 1206 5% (RoHS) 2
R20,R21,
Capacitors
141-c0101k50-e SMD capacitor 100pF 50V 10% 1206 NP0 (RoHS) 1
C4,
141-c0220k50-e SMD capacitor 22pF 50V 10% 1206 SMT NPO (RoHS) 1
C5,
141-c0561k50-e SMD capacitor 560pF 50V 10% 1206 NPO (RoHS) 1
C6,
141-c5104m50-e SMD capacitor 1206 Y5V 0.1uF 50V ±20% (RoHS) 8
C2,C3,C7,C8,C9,C10,C11,C15
,
141-c7223k50-e SMD capacitor 0.022uF 50V 10% 1206 X7R (RoHS) 1
C13,
141-d7104ka0-e SMD capacitor 0.1uF 100V 10% 1210 X7R (RoHS) 1
C12,
141-d7104kb5-e SMD capacitor 0.1uF 250V 10% 1210 X7R (RoHS) 5
C1,C18,C19,C20,C14
,
128-e106ma01k-e
non-polarity Electroytic CAP. 10UF 100V 20% 105℃ (RoHS)
2
C16,C17,
Semiconductors
190-16tl072dts-e
SMD I.C. TL072CDT SGS THOMSON DUAL OP-AMP
1
IC1,
192-09124126qs-e SMD Transistor 2SC2412K-T146Q/R ROHM (RoHS) 3
Q1,Q4,Q5,
192-09139066rs-e SMD Transistor 2SC3906K-T146R ROHM (RoHS) 2
Q2,Q8,
192-09210376qs-e SMD Transistor 2SA1037K-T146Q/R ROHM (RoHS) 2
Q7,Q9,
192-09215146rs-e SMD Transistor 2SA1514K-T146R ROHM (RoHS) 2
Q3,Q6,
197-03rls4148s-e SMD Diode RLS4148-TE11 ROHM (RoHS) 6
D1,D2,D3,D4,D5,D6,
199-15000563s-e SMD ZENER 5.6V 5% PHILIPS BZX84-C5V6 (RoHS) 2
Z1,Z2,
199-1500120s-e SMD ZENER 12V 5% PHILIPS BZX84-C12 (RoHS) 2
Z5,Z6,
199-15001503s-e SMD ZENER 15V 5% PHILIPS BZX84-C15 (RoHS) 2
Z3,Z4,
192-232irf9640-e FET IRF9640 IR P-CH TO220 (RoHS) 1
Q10,
192-233f640n-e Transistor IRF640N INTERNATIONAL (RoHS) 1
Q11,
CS100 (CS6100 Subwoofer)
