Part Number Description Qty
Reference Designato
Class D amp PCB (Replacment of entire module is recommended, part# 051-B00012A-E).
Miscellaneous
122-14121m4191-e Ferrite core 日 font LS-A6206-ST EFD-30 (RoHS) 1
L1,
122-14350j4180-e inductor 35uH Ferrite Core 25 Milliohm (RoHS) 1
L2,
175-9f40hr2-e Wire connector & base 40PIN PITCH=2.54mm HR2*40
MISCELLANEOUS/MECHANICAL
109-1ttc802j0-e thermistor Resistor TTC-802(JS) NTC long feet (RoHS) 1
TH1,
120-1000003-e
inductor 10W AI YT-C3104-005 1CRHW 354708LTB (RoHS)
2
FB1,FB2,
162-50129001-e CABLE ASS'Y row wire 120mm AWG28 WHT (RoHS) 1
W201,
171-urwh124d-e relay RWH-SH-124D (1600 ohm) (RoHS) 1
RL1,
150-r4055900-e Power transformer I/P:120V/60Hz TT0900008720 (RoHS) 1
T501,
152-u602015-e Line cord tie-in with polarity SVT FT-2 6FT both insulation 1
154-k31505t0-e Fuse 3.15A 250V 30mm UL/CSA/PSE (RoHS) 1
F501,
155-63032i-e Fuse holder HTB-32I 30mm UL/CSA (RoHS) 1
for F501,
156-h200040-e pyrocondensation sleeve 20ψ*40mm (RoHS) 1
156-h200050-e pyrocondensation sleeve 20Φ 50mm (RoHS) 1
162-10151001-e WIRE UL1617 150mm 22AWG BROWN 6:6 (RoHS) 1
162-a040d001-e speaker wire #1015 400mm 991110-00 (HG150 use ) (RoHS) 1
176-wjce1-e Wire connector pin CE-1 (RoHS) 1
180-pbr12c11s-e power switch PUSH BR12C11S (RoHS) 1
SW501,
193-201815t2-e ceramic insulator (RoHS) 2
302-AL-05092-0LAE Rear board 270*215*2.5T al, black printing CSC100 120V 1
306-ABS-00004-0BAE
Rear housing REAR CABINET 268*213*102 A.B.S UL (RoHS)
1
311-ABS-00028-0BAE
Plastic knob 46077-W soft material P.V.C. (RoHS) LEVEL
1
317-000-00037-0LAE earth end M3 solder t=0.3 (RoHS) 1
323-AL-00056-0LAE Heat sink 83.5*50.5*27.5H degrease 1
333-EVA-00096-0BAE EVA gasket wide side 213*15*2.0mm (RoHS) 2
333-EVA-00097-0BAE EVA gasket wide side 213*15*1.0t (RoHS) 2
333-EVA-00132-0BAE EVA gasket Long side 238*15*2.0mm (RoHS) 2
333-EVA-00133-0BAE EVA gasket Long side 238*15*1.0t (RoHS) 2
333-EVA-00188-0BAE EVA gasket 170x5x1t back with glue (RoHS) 1
333-EVA-00219-0BAE EVA gasket wide side 150*15*1t UL (RoHS) 1
333-EVA-00220-0BAE EVA gasket Long side 225*15*1t UL (RoHS) 1
335-NYL-05015-0BAE Line cord fixed button SB4F-2 black (RoHS) 2
350-EM04012D024-E 4￠*12 Wood screw electric black (RoHS) 4
351-AM03008A078-E M3*8 Machin screw plating nickel (RoHS) 4
351-AM03008A079-E M3*8 Machin screw electric black (RoHS) 3
352-AM03008D040-E ￠3*8 B ping screw electric black (RoHS) 2
352-AM03008D041-E ￠3*8 B ping screw plating nickel (RoHS) 2
352-AM03010D065-E ￠3*10 P ping screw electric black (RoHS) 2
352-HM03012D086-E ￠3*12 B ping screw electric black (RoHS) 1
CS100 (CS6100 Subwoofer)
