Parameter Specification Unit QA Test Limits Conditions
Notes
Transients/Pops
ATO Transient 5 mV-peak 10 @ Speaker Outputs
Turn-on Transient 50 mV-peak 100 @ Speaker Outputs
AC Line cycled from OFF to ON
Turn-off Transient 50 mV-peak 100 @ Speaker Outputs
AC Line cycled from ON to OFF
Efficienc
Stand-by Input Power 12 Watts 13
@ nom. line voltage Unit active, no
signal applied (Green LED)
Maximum allowable input power under
nominal Input voltage and frequency, HOT
or COLD operation.
Power Cons/Amps.@rated
power 120V Model
192 / 1.89 Watts/Amps 195 / 1.90 @ 120V-60 Hz (Nom.line voltage)
100 Watts @ 4 Ohms nominal line voltage
Power Cons/Amps.@rated
power230V Model
208 / 1.1 Watts/Amps 210 / 1.2 @ 230V-50 Hz (Nom.line voltage)
100 Watts @ 4 Ohms nominal line voltage
Protection
Short Circuit Protection YES -- Functional Direct short at output
Thermal Protection 65 deg. C -- Functional @1/8 max unclipped Power
Temperature rise should not exceed 35K
rise
DC Offset Protection YES -- Functional DC present at Speaker Out leads
Relay or crowbar (for driver/fire protection)
Line Fuse Rating
120VAC 2.5 Amps Type-T or Slo Blo
External fuse with UL/SEMKO rated holder
230VAC 1.25 Amps Type-T or Slo Blo
External fuse with UL/SEMKO rated holder
CS80 (CS480 Subwoofer)
