JBL GTH400 - Connection Diagrams

15
FACE PLATE
DASH PANEL
SPACER
PLATE (INCLUDED)
FACE PLATE
Cassette/CD Tuner
CD Player
or Changer
CD Input
Cassette/CD Preamp Output
Antenna Input
Power
Antenna
Power
Antenna
Relay
Blue w/White Stripe - Remote On/Off
Main +12V
Power Ground
Chassis Ground
Vehicle Battery
–
+
Ignition Switch
Antenna
Motor
Power
Supply
Blue (Blue/White)
Remote On/Off
Remote Antenna
Black - Power Ground
Red - Main +12V
Yellow - Back Up Power
Fuse Fuse
Fuse
Cassette/Receiver
Power Supply
Wires
Speakers
+
–
+
Speakers
+
–
+
Speakers
+
–
+
60 Amp
(Not Included)
Amplifier
Power
Connection
Amplifier
Speaker
Output
Connection
Amplifier
Speaker
Output
Connection
Amplifier
Speaker
Output
Connection
Amplifier
Speaker
Level
Inputs
Cassette/CD Tuner
Speaker Level Output Connection
(Use only when line level ouput
is not available)
IMAGING ENHANCER
GTH400-20107 06/03/98 15:49 Side 15
