7
Specifications LXE330 LXE550 LXE770 LXE990
High Frequency 1" Pure 1" Pure 1" Pure 1" Pure
Dome Transducer Titanium Titanium Titanium Titanium
Midrange Transducer n/a n/a 5" 5"
(High Polymer Laminate Cone)
Low Frequency Transducer 6
1
/2" 8" 8" 10"
(High Polymer Laminate Cone)
Crossover Frequency 3.7 kHz 2.3 kHz 760/3.7 kHz 800/3.2 kHz
Frequency 55 Hz to 41 Hz to 41 Hz to 40 Hz to
Response (– 6 dB) 23 kHz 23 kHz 23 kHz 23 kHz
Sensitivity (1 Watt/1 meter) 90 dB 91 dB 91 dB 92 dB
Nominal Impedance 8 ohms 8 ohms 8 ohms 8 ohms
Recommended 10 to 125 10 to 140 10 to 150 10 to 200
Amplifier Power* Watts Watts Watts Watts
External Dimensions
Height 17
3
/8"23
1
/8" 26" 28
1
/2"
Width 9
5
/8"12
1
/8"12
1
/8"13
1
/2"
Depth 6
3
/4"8
15
/16"8
15
/16"8
15
/16"
External Dimensions
Height 441 mm 587 mm 660 mm 724 mm
Width 245 mm 308 mm 308 mm 343 mm
Depth 172 mm 227 mm 227 mm 227 mm
Weight (each) 15 lbs 24 lbs 29 lbs 33 lbs
6.8 kg 10.9 kg 13.2 kg 15.0 kg
Shipping Weight 34 lbs 52 lbs 33 lbs 37 lbs
15.4 kg 23.6 kg 15.0 kg 16.8 kg
*The maximum recommended amplifier power rating will ensure proper system headroom to allow for
occasional program peaks. We do not recommend sustained operation at these maximum power Levels.
JBL continually strives to improve its products. New materials, production methods and design refinements
are introduced into existing models without notice as a routine expression of our design philosophy. For this
reason, JBL LXE Series Loudspeakers may differ in some respect from their published specifications
and descriptions, but will always equal or exceed the original specifications unless otherwise stated.
LXE owners manual 7/27/98 4:34 PM Page 6
