Installing tips
o Make sure to connect a (summed) full-range signal to the inputs of MS-8
• Every Left inputs of MS-8 will be summed and Right inputs will be summed
• Subwoofers need to be connected to input 7 and/or input 8
• No need to connect center to the input (MS-8 will create even a better center channel
channel)
o Connect REM IN to remote turn on lead or ACC/+15 ignition wire
• This is better than an auto/sensing switch-on because this prevents switching on- and off
pops. Also MS-8 needs to be switched on always to process telephone calls, park distance
control signals even when your radio is off.
Set-up tips
o Make sure bass/treble/balance/fader of OEM system is FLAT and OEM equalizers/dsp functions
are OFF
o When assigning Xover frequencies note that OEM subwoofers (like under seat subs in BMW,
woofer in back shelf of Audi A4 or door woofers Audi A6 have an Xover frequency around
200Hz) make sure to use the right (measured) Xover frequencies
o When you have to select Sub (None, 1, 2) this doesn’t mean the number of subwoofers you’ve
installed but the number of (RCA)outputs you will need
o When you have to select Front/Rear (1 way, 2 way and 3 way) this refers to the number of
outputs you will need
Acoustic calibration
o Make sure all speakers and subwoofers are playing on the same volume
when you calibrate MS-8
(Adjust input sensitivity and sublevels amplifiers to match with each other and OEM)
o Make sure to calibrate at volume level -20dB at MS-8
(-25/-30dB when additional amplifiers are used)
(Calibration is done by MLS measurement, when you would clip the calibration signal the result
would be disappointing)
After calibration
o Raise the volume of MS-8 back to -5dB/0dB
o If in your opinion have not enough bass increase the subwoofer level (this is a shelf filter which
means it increases al frequencies below 60Hz) or increase the input sensitivity/bass level of
subwoofer amplifier
