JBL Nano Patch+ - Nano Patch+ Specifications; Audio Inputs; Audio Outputs; Performance

SPECIFICATIONS
Audio Inputs: Input Connectors 1 2 x Combination XLR/TRS 1/4-inch (6.5mm)
balanced/unbalanced
Input Connectors 2 1 x 1/8 inch (3.5mm) Mini Jack
Maximum Input Level +26dB
Input Impedance 5K ohms
Audio Outputs: Output Connectors 1 2 x TRS 1/4 inch (6.5mm)
balanced/unbalanced
Max Output Level > +26dB
Output Connectors 2 1 1/8 inch (3.5mm) Mini Jack
Impedance 0-5K ohms
Performance: Frequency Response 0/0.15dB (10Hz - 40KHz)
Signal-To-Noise better than -120dB
Channel Cross Talk > -80dB
Distortion < 0.0004%
Physical: Dimensions (W x D x H) 5.1 in x 3.75 in x 2.0 in
(130 mm x 95 mm x 51 mm)
Weight 0.8 lbs (.34 kg)
