Parts and description
1
JBL PROFLORA CO₂ CONTROL measuring and display unit
2
Power supply unit 12 V DC
3
Temperature sensor
4
Connecting cable for solenoid valve
5
Suction holder for temperature sensor (2 x)
6
Top-hat rail
7
Screws with dowels (2 x each)
8
Holder for calibration cuvettes
!
JBL PROFLORA CO₂ pH SENSOR SET (please purchase separately!)
Installation
The illustration (Page 4) shows a typical installation example.
1
Measuring and control device JBL PROFLORA CO₂ CONTROL
A
Coloured touch display
B
Input socket for power supply 12 V DC
C
Input socket for temperature sensor
D
BNC connection for pH sensor
E
12 V DC output socket for connecting cable for solenoid valve
2
Power supply unit 12 V DC
3
Temperature sensor
4
Connecting cable for solenoid valve
9
JBL PROFLORA CO₂ pH SENSOR SET
10
CO
2
reactor JBL PROFLORA CO₂ TAIFUN SPIRAL
11
Bubble counter with integrated backflow protection JBL PROFLORA CO₂ TAIFUN COUNT SAFE
12
Solenoid valve JBL PROFLORA CO₂ VALVE
13
JBL PROFLORA CO₂ TAIFUN TUBE BLACK Special CO
2
hose
14
JBL PROAQUATEST CO
2
-pH Permanent
