13
PRX815XLFW PRX818XLFW
SYSTEM SPEC
System Type: Self powered 15”, bass-reflex Self powered 18”, bass-reflex
Max SPL Output: 131 dB 134 dB
Frequency Range (-10
dB):
36 Hz – 113 Hz 30 Hz – 103 Hz
Frequency Response
(±3 dB):
40 Hz – 91 Hz 35 Hz – 87 Hz
Input Connectors:
Two Balanced female XLR/ 1/4”
combo connectors
Two Balanced female XLR/ 1/4”
combo connectors
Input Impedance: 20K Ohms (balanced) 20K Ohms (balanced)
Signal Indicators: Limit: Yellow LED indicates input
is clipping or peak output has
been reached and the DSP limiter
is acting.
Signal: Green LED indicates signal
present.
Power: Blue indicates system has
power and ready to pass audio.
Limit: Yellow LED indicates input
is clipping or peak output has
been reached and the DSP limiter
is acting.
Signal: Green LED indicates signal
present
Power: Blue indicates system has
power and ready to pass audio.
EQ: n/a n/a
Dynamic Control (Input): dbx Type IV™ limiter circuit dbx Type IV™ limiter circuit
Crossover
Frequency:
Internal: 80 Hz DSP controlled 48
dB filter slope
Internal: 80 Hz DSP controlled 48
dB filter slope
AMPLIFIER
Design: Class-D Class-D
Power Rating: 1500W 1500W
SPEAKER
LF: 1 x JBL 2275H 15 in woofer 1 x JBL 2278G 460 mm (18 in)
woofer
MF: n/a n/a
HF: n/a n/a
Coverage Pattern: n/a n/a
Directivity Index (DI): n/a n/a
Directivity Factor (Q): n/a n/a
Enclosure: Rectangular, 18 mm & 25mm,
plywood
Rectangular, 18 mm, plywood
Suspension/Mounting: n/a n/a
Transport: 2 x injection molded handles with
backing cup
2 x injection molded handles with
backing cup
Finish: Obsidian DuraFlex™ finish Obsidian DuraFlex™ finish
Grille: Powder coated, Obsidian, 16
gauge perforated steel with
acoustical transparent black cloth
backing.
Powder coated, Obsidian, 16
gauge perforated steel with
acoustical transparent black cloth
backing.
Dimensions (mm):
(H x W x D) (in):
548 x 446 x 572
21.6 x 17.5 x 22.5
692 x 523 x 724
27.26 x 20.6 x 28.5
Net Weight: 25.4 kg (56 lb) 36.8 kg (81 lb)
SYSTEM SPECIFICATIONS
Subwoofers
