011 TECH SPEC
Driver size: 50 mm Dynamic drivers
Frequency response: 20 Hz - 20 kHz
Microphone frequency response: 100 Hz -10 kHz
Max input power 30 mW
Sensitivity: 100 dB SPL @1 kHz / 1 mW
Maximum SPL: 97 dB
Microphone sensitivity: -40 dBV @1 kHz / Pa
Impedance: 32 ohm
2.4G Wireless transmitter power: <4 dBm
2.4G Wireless modulation: π/4-DQPSK
2.4G Wireless carrier frequency: 2403.35 MHz - 2479.35 MHz
Battery type: Li-ion battery (3.7 V / 1000 mAh)
Power supply: 5 V 2 A
Charging time: 2 hrs
Music play time with RGB lighting o: 14 hrs
Microphone pickup pattern: Unidirectional
Weight: 346 g
