Anti-Slip Pad’s
Use the included Anti Slip Pads on the 250B/240B and 245C to prevent them from moving. Optional Floorstands for the 250B/240B are
available.
Wall Mounting 240B
The 240B is designed with multiple mounting options. It can be used on a bookshelf, with the optional FL Floorstands, mounted to the
wall using the include wall brackets and hardware or utilizing the ½-20 threaded insert to use aftermarket mounting brackets.
When using the included wall bracket:
• Use the included wall brackets to mark the positions on the wall where you would like to place the mounting screws.
• Mount the include bracket to the rear of each speaker using the included hardware (2 screws).
• Each bracket has two keyholes on the back and will require 2 4.0 x 38mm wood screws or equivalent fastened to a wall stud. If a wall
stud is not available install a wall anchor capable of supporting the weight of the speaker and can use 4.0 x 38mm screws.
• Insert the Foam Plug.
Front
Bottom Bottom
Front
Keyholes
