www.jbl.com
14
STUDIO 120c CENTERCHANNEL SPEAKER
Speaker type: 2-1/2-way dual center-channel
Low-frequency transducer: Two 4" (100mm) PolyPlas cones, magnetically shielded
High-frequency transducer:
1" CMMD Lite dome, magnetically shielded, in a Bi-Radial
constant-directivity waveguide
Power handling: 60 watts (continuous); 240 watts (peak)
Frequency response: 60Hz – 22kHz
Nominal impedance: 8 ohms
Sensitivity (2.83V/1m): 90dB
Crossover frequencies: 900Hz, 12dB/octave; 1.8kHz, 24dB/octave
Enclosure type: Ported
Connector type: Gold-plated binding posts
Dimensions (H x W x D): 6-1/2" x 21" x 9-7/8" (165mm x 533mm x 251mm)
Weight: 18.6 lb (8.4kg)
STUDIO 130 BOOKSHELF SPEAKER
Speaker type: Two-way bookshelf
Low-frequency transducer: 4" (100mm) PolyPlas cone, magnetically shielded
High-frequency transducer:
1" CMMD Lite dome, magnetically shielded, in a Bi-Radial
constant-directivity waveguide
Power handling: 60 watts (continuous); 240 watts (peak)
Frequency response: 60Hz – 22kHz
Nominal impedance: 8 ohms
Sensitivity (2.83V/1m): 87dB
Crossover frequencies: 3kHz, 12dB/octave
Enclosure type: Ported
Connector type: Gold-plated binding posts
Dimensions (H x W x D): 13-3/4" x 6-1/2" x 8-1/4" (349mm x 165mm x 210mm)
Weight: 10.9 lb (4.9kg)
