STUDIO 130 SURROUND CHANNELS 7.1CHANNEL SYSTEM
When you use
Studio 130 speakers as surround-channel speakers in a 7.1-channel system, place the surround side
speakers directly to the sides of the listening position, at least 5 – 6 feet (1.5m – 1.8m) above the floor. Place the surround
back speakers on the wall behind the listening position, also at least 5 – 6 feet (1.5m – 1.8m) above the floor and 3 – 6
feet (0.9m – 1.8m) apart.
Studio
190/180/130
Front Left
Speaker
Studio 130 Surround
Left Back Speaker
Studio 130 Surround Right
Back Speaker
TV
Studio 120c
Center Speaker
3 – 6 ft apart
(0.9m – 1.8m)
Studio
190/180/130
Front Right
Speaker
Studio 130
Surround Left
Side Speaker
Studio 130
Surround Right
Side Speaker
