ENGLISH USER MANUAL
JB SYSTEMS
®
7/63 TWIN EFFECT LASER
1 CHANNEL DMX-CONFIGURATION OF THE LASER:
CHANNEL VALUE DESCRIPTION
CH 1
MODES
000-024 Laser OFF (Black out)
025-059 AUd mode (Auto grating effects show)
060-099 AUP mode (Auto pattern effects show)
100-139 AUn mode (Auto grating + pattern effects show)
140-179 Sod mode (Sound active grating effects show)
180-219 SoP mode (Sound active pattern effects show)
220-255 Son mode (Sound active grating / pattern effects show)
10 CHANNEL DMX-CONFIGURATION OF THE LASER:
IMPORTANT REMARK: DMX Channel1 is used to set the different working modes of the laser.
To use the laser in full 10 channel mode, channel 1 must be set to value 175 or higher.
Depending on the DMX-values of channel1, 3 different charts can be applied:
Value between 175 and 199: see chart “10CH DMX-chart 10-A”
Value between 200 and 224: see chart “10CH DMX-chart 10-B”
Value between 225 and 255: see chart “10CH DMX-chart 10-C”
CHANNEL VALUE DESCRIPTION
CH 1
MODES
000-024 Laser OFF (Black out)
025-049 AUn mode (Auto grating + pattern effects show)
050-074 Son mode (Sound active grating / pattern effects show)
075-099 AUP mode (Auto pattern effects show)
100-124 SoP mode (Sound active pattern effects show)
125-149 AUd mode (Auto grating effects show)
150-174 Sod mode (Sound active grating effects show)
175-199
DMX mode with GRATING DOT effects
see 10CH DMX-table 10-A
200-224
DMX mode with GRATING PATTERN effects
see 10CH DMX-table 10-B
225-255
DMX mode with traditional pattern effects
see 10CH DMX-table 10-C
10CH DMX-chart 10-A (DMX CHANNEL1 set between values 175 and 199)
CHANNEL VALUE DESCRIPTION
CH 2
X AXIS MOVING
000-127 128 different fixed positions on X-axis
128-191 Clockwise moving
192-255 Anticlockwise moving
CH 3
Y AXIS MOVING
000-127 128 different fixed positions on Y-axis
128-191 Clockwise moving
192-255 Anticlockwise moving
CH 4
COLORS
000-009 Laser blackout
010-063 Red + green ON or red & green strobing
064-127 Red ON or red strobe & green OFF
128-191 Green ON or green strobe & red OFF
192-255 Red + green ON or red & green strobing alternately
CH 5
STROBE
000-009 No Strobing
010-249 Strobing (low to high speed)
250-255 Strobing to the music
ENGLISH USER MANUAL
JB SYSTEMS
®
8/63 TWIN EFFECT LASER
GRATING
ROTATION
000-075 Clockwise rotation (low to high speed)
076-150 No rotation
151-255 Anticlockwise rotation (low to high speed)
NOT USED
10CH DMX-chart 10-B (DMX CHANNEL1 set between values 200 and 224)
CHANNEL VALUE DESCRIPTION
CH 2
000-255 11 different grating patterns
CH 3
ZOOMING
000-127 Pattern size: from big (100%) to small (5%)
128-169 Zooming in (from big to small + from slow to fast)
170-209 Zooming out (from small to big + from slow to fast)
210-255 Zooming in & out (from slow to fast)
CH 4
Y AXIS
ROLLING
000-127 0° to 359° fixed positions around Y axis
128-191 Clockwise rolling around Y axis
192-255 Anticlockwise rolling around Y axis
CH 5
X AXIS
ROLLING
000-127 0° to 359° fixed positions around X axis
128-191 Clockwise rolling around X axis
192-255 Anticlockwise rolling around X axis
CH 6
Z AXIS
ROLLING
000-127 0° to 359° fixed positions around Z axis
128-191 Clockwise rolling around Z axis
192-255 Anticlockwise rolling around Z axis
CH 7
X AXIS MOVING
000-127 128 different fixed positions along the X axis
128-191 Clockwise moving along the X axis
192-255 Anticlockwise moving along the X axis
CH 8
Y AXIS MOVING
000-127 128 different fixed positions along the Y axis
128-191 Clockwise moving along the Y axis
192-255 Anticlockwise moving along the Y axis
CH 9
COLOR
000-016 RED
017-031 GREEN
032-049 RED & GREEN
050-255 Changing colors
CH 10
GRATING
ROTATION
000 No grating rotation
001-075 Clockwise grating rotation
076-150 NO grating rotation
151-255 Anticlockwise grating rotation
