jcb 16c-1 - Main Component Locations

About the Product
Description
9 9831/2900-4 9
Before you do a maintenance task, make the product safe.
Main Component Locations
Figure 3.
A
C
G
E
F
D
B
A Cab/canopy (contains the operator station) B Boom (part of the excavator arm)
C Dipper (part of the excavator arm) D Bucket
E Dozer blade F Undercarriage
G Upper structure
