jcb 260T - Page 39

01 - Machine
09 - Description
15 - Service Point Locations
01 - 33 9813/5150-2 01 - 33
(For: 225T [T3 GE0], 225T [T4F GE0], 260 [T3 GE0], 260 [T4F GE0], 260T [T3 GE0],
260T [T4F GE0], 280 [T3 GE0], 280 [T4F GE0], 300 [T3 GE0], 300 [T4F GE0], 300T [T3
GE0], 300T [T4F GE0], 320T [T3 GE0], 320T [T4F GE0], 325T [T4F GE0], 330 [T3 GE0],
330 [T4F GE0])
Wheeled Machines
Figure 17.
A
B
C
F
G
H
J
E
K
D
L
M
A Coolant expansion bottle B Fuel sedimenter
