jcb 354 - Standard Torque Settings; Front Axle Housing and Transmission

Section 1 - General Information
1 - 5 1 - 5
9803-9480-1
Standard Torque Settings
Front Axle Housing and Transmission
Introduction
The following table gives the torque tightening values for
the major parts of the Front Axle Housing (4WD Type) and
the Transmission.
Table 1. Standard Torque Settings
Major Part Bolt and Nut Size
(Hardness)
Torque Value
Nm kgf/m lbf/ft
Front Axle Housing
Axle bracket to engine 5/8-11UNC (9T) 156.9 - 176.5 16.0 - 18.0 115.7 - 130.2
Front pivot metal M14 (9T) 156.9 - 176.5 16.0 - 18.0 115.7 - 130.2
Rear pivot metal M18 (7T) 196.0 - 235.2 20.0 - 24.0 144.6 - 173.5
Front axle final case M12 (7T) 88.2 - 107.9 9.0 - 11.0 65.1 - 79.6
Bearing cover M14 (7T) 132.3 - 137.2 13.5 - 14.0 97.6 - 101.2
Wheel shaft cover M8 (7T) 53.9 - 68.6 5.5 - 7.0 39.8 - 50.6
Front wheel M18 (7T) 225.4 - 235.2 23.0 - 24.0 166.3 - 173.5
Bevel gear case M12 (7T) 88.2 - 107.9 9.0 - 11.0 65.1 - 79.6
Diff-metal (support) M10 (7T) 73.5 - 87.2 7.5 - 8.9 9.4 - 13.1
Transmission
Front transmission - engine M12 (7T) 88.2 - 107.9 9.0 - 11.0 65.1 - 79.6
Front transmission - spacer M12 (7T) 88.2 - 107.9 9.0 - 11.0 65.1 - 79.6
Space transmission - rear transmission M12 (7T) 88.2 - 107.9 9.0 - 11.0 65.1 - 79.6
Input metal (support) M12 (7T) 88.2 - 107.9 9.0 - 11.0 65.1 - 79.6
Drive pinion metal (support) M10 (7T) 53.9 - 68.6 5.5 - 7.0 39.8 - 50.6
Drive pinion
Diff-case metal (support) M12 53.9 - 68.6 5.5 - 7.0 39.8 - 50.6
Diff-case ring gear M12 (7T) 88.2 - 107.9 9.0 - 11.0 65.1 - 79.6
