About the Product
Description
11 9831/3050-3 11
Figure 6.
A ROPS (Roll-Over Protective Structure)/FOPS
(Falling Object Protective Structure) cab
B Shovel
C Fuel tank D Kingpost
E Drivehead ( 100 mm square) F Internal kelly bars
G Kelly bar H Kelly bar guide
J Rotary drivehead K Motor (x3)
L Pulley M Winch motor
N Swivel P Depth guage and piling head carriage
Q Winch R Stabilisers
S Steps T Hydraulic oil tank
U Loader arm V Boom
W Hand held tool reel X Bonnet
