jcb JCB-PP1050 - Component List

JCB, SO53 3LE
www.JCBDIY.com
Customer Helpline 0333 0143092
1. LOCK-OFF SWITCH
2. ON/OFF SWITCH
3. HAND GRIP AREA
4. DUST EXTRACTION OUTLET
5. BELT COVER
6. FASTENING BOLT
7. REBATE PARALLEL GUIDE
8. LOCKING SCREW
9. BASE PLATE
10. V-GROOVES
11. REBATE DEPTH GAUGE
12. CUTTING DEPTH ADJUSTMENT
13. BLADE (See D1)
14. BLADE CLAMP (See D1)
15. SPANNER (See D1)
16. LARGE PULLEY (See E)
17. PINION (See E)
18. DUST COVER
COMPONENT LIST
*Not all the accessories illustrated or described are included in standard delivery.
91011
4
6
12
18
1 2 3
5
6
7
8
