Section 1 - General Information
Service Tools
Tool Detail Reference Section C - Electrics
1 - 15
9803-6530
1 - 15
Fig 19. 892/01174
1 Interconnecting cable, DLA to machine ECU
diagnostics socket.
2 Interconnecting cable, DLA to machine ECU
diagnostics socket.
3 Kit carrying case.
4 USB Interconnecting cable, DLA to laptop PC.
5 USB Data Link Adaptor (DLA), enables data
exchange between the machine ECU (Electronic
Control Unit) and a laptop PC loaded with the
applicable diagnostics software.
6 Serial Interconnecting cable, DLA to laptop PC.
D
F
AB
C
H
J
E
G
3
5
6
4
1
2
