About the Product
Description
9 9821/9300-4 9
Figure 3.
A Exhaust B Engine compartment
C Articulation lock D Shovel/attachment
E Lift arm/boom F ROPS (Roll-Over Protective Structure)FOPS
(Falling Object Protective Structure)
G Recovery hitch H Trailer socket and battery isolation switch
(battery isolation switch positioned either
inside or outside the engine bay depending on
specification of the machine)
