STEERING GEAR
CABLE ADJUSTMENT - STEERING SYSTEM
The steering gear is assembled and pre-adjusted at the factory, however, only actual
use at sea will enable the steering cable to find its definitive postion around the wheel drum.
For this reason, it is necessary to re-adjust the gear after the first few sea outings.
The adjustment is made on the nut and bolt system integral with the steering cable at the
join with the profile. To check the adjustment exert a perpendicular force on the cable
between the wheel drum and the return sheaves located on the hull. The slack in the cable
should not exceed 10 mm. The adjustment is carried out in the same way on the 2 sides of
the cable(see diagram).
MAINTENANCE
- Regularly check:
• The tension in the steering cables.
• The tightness of the steering system components.
- Don't tighten the steering cables excessively.
- Lubricate all the elements.
Maintain the nylon, ertalon or teflon bushes with only a suitable lubricant.
Note: Do not hesitate to consult your dealer about system maintenance.
WARNING
- The steering system is a feature of sailing safety and for this reason must
be verified at least once a year.
-T
HE STEERING CABLE MUST BE CHANGED EVERY 4 YEARS.
WARNING
- Refer to chapter 2 "Safety"for use of the emergency tiller.
ADVICE - RECOMMENDATION
- The emergency tiller is designed only to be able to continue underway at a reduced
speed in case of steering gear failure.
5
STEERING SYSTEM
