84/148
Drainage - Galley sink + Draining rack
Icebox drainage: directly to well.
Drainage - Dishwasher:
Connector to sink drain in kitchen
cabinet.
Drainage - Head version
Shower + Washbasin
Port aft head compartment
Shower + Washbasin
Starboard aft head compartment
Ordering evacuation shower Drainage - Washer: Starboard saloon
