TOILET OPERATION QUIET FLUSH (OPTIONAL)
USE OF MARINE HEADS EQUIPPED WITH A WASTE HOLDING TANK (WHT)
Open the water intake valve (valve handle parallel to the pipe).
In the case of a direct discharge into the sea: Open the draining valve.
In case you store the waste waters in the tank: Make sure the draining valve is closed
(valve handle perpendicular to the pipe).
To drain the bowl, set the control lever of the pump slantwise (FLUSH) then operate the
pump.
To dry the bowl, set the lever vertical (DRY) then operate the pump.
Control WC quiet flush
1. Rinsing out the bowl
2. Water filling to the left and bowl draining to the right
Pump Seawater inlet + Filter
1. Seawater inlet - WC
2. Filter
3. Pump - WC
2
1
