Cavity Fuse Description
1 20 Amp Yellow Park Lights, Skim (Sentry
Key)
2 20 Amp Yellow Stop Lights
3 20 Amp Yellow Subwoofer System
4 10 Amp Red Door Switch Defeat
5 10 Amp Red Airbag
6 20 Amp Yellow Rear Wiper
7 10 Amp Red Back-Up Lights, Rear
Window Defroster Relay,
ABS
8 10 Amp Red HEVAC
9 10 Amp Red Airbag
10 10 Amp Red Instrument Cluster
11 10 Amp Red Solenoids, DRL
Cavity Fuse Description
12 10 Amp Red Power Distribution Re-
lays, Skim (Sentry Key)
13 10 Amp Red Turn Signals
14 10 Amp Red Radio
15 10 Amp Red HBL (Rear Window De-
froster) Switch
16 10 Amp Red Headlamp Aim (Export
Only)
17 25 Amp Natu-
ral
Front Wiper
18 20 Amp Yellow Cigar Lighter
19 20 Amp Yellow Spare
20 20 Amp Yellow Spare
306 MAINTAINING YOUR VEHICLE
