Cav-
ity
Cartridge
Fuse
Mini-Fuse Description
3 10 Amp
Red
Htd Mirror (EBL)
4 20 Amp
Yellow
Rr Pwr Out (B+)
5 10 Amp
Red
Rr HVAC (R/O)
(Commander Only)
6 Spare (B+)
7 20 Amp
Yellow
Door Locks (B+)
8 Spare (B+)
9 20 Amp
Yellow
Pwr Outlet (B+)
Cav-
ity
Cartridge
Fuse
Mini-Fuse Description
10 10 Amp
Red
Final Drive Control
Module (FDCM),
Heater Ventilation/
Air Conditioning
(HVAC), Rear Heated
Seat Switch, O/H,
Heater Ventilation/
Air Conditioning
(HVAC) Relay, Rear
Park Assist
11 Spare (B+)
12 10 Amp
Red
Door Mods, O/H
Lamps, IP Courtesy
Lamps, Glove Box
Lamp (B+)
13 10 Amp
Red
Autowipe (R/A)
7
MAINTAINING YOUR VEHICLE 393
