3. Pull the outboard side of the rear lamp unit rearward
far enough to unsnap the two ball studs on the outboard
side of the lamp housing from the two plastic grommets
in the quarter outer panel. Pull the lamp unit rearward
far enough away to access the bulbs.
4. Firmly grasp the appropriate bulb socket on the back
of the rear lamp unit housing, and turn 1/4 turn coun-
terclockwise to unlock it.
1 — Rear Backup Lamp Bulb
2 — Rear Park/Stop Lamp Bulb
3 — Rear Park/Turn Signal Bulb
4 — Rear Side Marker Lamp Bulb
7
MAINTAINING YOUR VEHICLE 405
