Cavity Maxi Fuse Cartridge Fuse Mini Fuse Description
F07 40 Amp Orange – – Rear Distribution Unit For Trailer
Tow Usage
F08 – 30 Amp Pink – Supply for F24, F87, Steering
Control
F09 – – 7.5 Amp Brown Control Module Engine
F10 – – 20 Amp Yellow Horn
F11 – – 20 Amp Yellow – 1.4L Gas &
Diesel Engines
25 Amp Clear – 2.4 L Engines
Supply Secondary Loads
F14 – – 7.5 Amp Brown Diesel Crankcase Heater
F15 40 Amp Orange – – Brake Control Module Pump
F16 – – 10 Amp Red Engine Control Module Power,
Automatic Transmission
F17 – – 10 Amp Red Engine Secondary Loads
F18 – – 20 Amp Yellow 12V Rear Cargo Outlet Ignition
Powered
F19 – – 7.5 Amp Brown Air Conditioner Compressor and
PWM Rad Fan enable
F20 – – 20 Amp Yellow Cigar Lighter
F21 – – 15 Amp Blue Fuel Pump
F22 – – 20 Amp Yellow – Gas Engine
15 Amp Blue – Diesel Engine
Power Control Module Engine
F23 – – 30 Amp Green Window Heater Grid
F24 – – 15 Amp Blue Electronic Unit Supply Automatic
Transmission
