LIGHTS BULBS – Exterior Bulb No.
Low Beam Headlamp .....................H11
High Beam Headlamp ....................9005
Front Park/Turn Signal Lamp ............7444NA
Front Side Marker Lamp ................... 194
Front Fog Lamp ......................... H11
Center High Mounted Stop
Lamp (CHMSL) ..................LEDAssembly
(Serviced at Authorized Dealer)
Rear Tail/Stop Lamp .....................LED
(Serviced at Authorized Dealer)
Rear Turn Lamp ..........7440NA (WY21W) Amber
Backup Lamp ...............7440 (W21W) Crystal
License Lamp..........................W5W
BULB REPLACEMENT
Headlamps
1. Raise the hood and locate the connector behind the
headlamp.
2. Reach into the engine compartment and pull the red
lock out at the green connector.
3. Remove green connector from back of bulb by pulling
straight back.
4. Twist the bulb to the left.
5. Pull bulb outward from assembly.
NOTE: These are halogen bulbs. Take care not to touch
the bulb with your fingers. Body oils from your fingers
could cause excessive heat buildup which reduces bulb
life.
Fog Lamps
1. Access lamp through the lower fascia cutout.
2. Remove electrical connector from bulb.
3. Remove bulb from housing.
7
MAINTAINING YOUR VEHICLE 445
