2. There is no fuel filler cap. A flapper door inside the pipe
seals the system.
3. Insert the fuel nozzle fully into the filler pipe; the nozzle
opens and holds the flapper door while refueling.
4. Fill the vehicle with fuel, and when the fuel nozzle
“clicks” or shuts off, the fuel tank is full.
5. Wait ten seconds before removing the fuel nozzle to
allow fuel to drain from nozzle.
6. Remove the fuel nozzle and close the fuel door.
Emergency Gas Can Refueling
Most gas cans will not open the flapper door. A funnel is
provided to open the flapper door to allow emergency
refueling with a gas can.
1. Retrieve funnel from the spare tire storage area.
2. Insert funnel into same filler pipe opening as the fuel
nozzle.
3. Ensure funnel is inserted fully to hold flapper door
open.
4. Pour fuel into funnel opening.
Filling Procedure
Fuel Funnel
278 STARTING AND OPERATING
