Symptom List:
LEFT FRONT WHEEL SPEED SENSOR CIRCUIT
REAR WHEEL SPEED SENSOR CIRCUIT
RIGHT FRONT WHEEL SPEED SENSOR CIRCUIT
Test Note: All symptoms listed above are diagnosed using the same tests.
The title for the tests will be LEFT FRONT WHEEL SPEED
SENSOR CIRCUIT.
When Monitored and Set Condition:
LEFT FRONT WHEEL SPEED SENSOR CIRCUIT
When Monitored: Ignition On - Continuously
Set Condition: When the ABM detects a wheel speed sensor circuit current is out of
range.
REAR WHEEL SPEED SENSOR CIRCUIT
When Monitored: Ignition On - Continuously
Set Condition: When the ABM detects a wheel speed sensor circuit current is out of
range.
RIGHT FRONT WHEEL SPEED SENSOR CIRCUIT
When Monitored: Ignition On - Continuously
Set Condition: When the ABM detects a wheel speed sensor circuit current is out of
range.
POSSIBLE CAUSES
INTERMITTENT CONDITION
WHEEL SPEED SENSOR OR CONNECTOR DAMAGE
WHEEL SPEED SENSOR SIGNAL CIRCUIT FAULT
WHEEL SPEED SENSOR 12 VOLT SUPPLY CIRCUIT SHORT TO GROUND
WHEEL SPEED SENSOR 12 VOLT SUPPLY CIRCUIT OPEN
WHEEL SPEED SENSOR SIGNAL CIRCUIT SHORT TO GROUND
WHEEL SPEED SENSOR SIGNAL CIRCUIT OPEN
ABM - 12 VOLT SUPPLY CIRCUIT FAULT
ABM - SIGNAL CIRCUIT FAULT
WHEEL SPEED SENSOR 12 VOLT SUPPLY SHORT TO GROUND
WHEEL SPEED SENSOR SIGNAL CIRCUIT INOPERATIVE
17
BRAKES (25E)
