Jenn-Air JS48PPDBDA - Installation Guide

Exterior Dimensions (in/cm) 48" STAINLESS STEEL 48" OVERLAY 48" FRAMED 42" STAINLESS STEEL 42" OVERLAY 42" FRAMED
Model Numbers JS48PPDBDA JS42PPDBDA
JS48PPFXDA JS42PPFXDA
JS48SEDBDA JS48CSD*DA JS48F*D*DA JS42SEDBDA JS42CSD*DA JS42F*D*DA
JS48SEFXDA JS48CSFXDA JS48F*FXDA JS42SEFXDA JS42CSFXDA JS42F*FXDA
in cm in cm in cm in cm in cm in cm
A. Cutout Height 83
3
⁄4 212.7 83
3
⁄4 212.7 83
3
⁄4 212.7 83
3
⁄4 212.7 83
3
⁄4 212.7 83
3
⁄4 212.7
B. Cutout Width 47
1
⁄2 120.7 47
1
⁄2 120.7 47
1
⁄2 120.7 41
1
⁄2 105.4 41
1
⁄2 105.4 41
1
⁄2 105.4
C. Cutout Depth 24 61.0 24 61.0 24 61.0 24 61.0 24 61.0 24 61.0
D. Height to Top of Cabinet
†
83
1
⁄16 210.9 83
1
⁄16 210.9 83
1
⁄16 210.9 83
1
⁄16 210.9 83
1
⁄16 210.9 83
1
⁄16 210.9
E. Height to Top of Grille 83
3
⁄8 211.8 83
3
⁄8 211.8 83
3
⁄8 211.8 83
3
⁄8 211.8 83
3
⁄8 211.8 83
3
⁄8 211.8
F. Width (cabinet) 47
1
⁄4 120.0 47
1
⁄4 120.0 47
1
⁄4 120.0 41
1
⁄4 104.8 41
1
⁄4 104.8 41
1
⁄4 104.8
G. Width (doors closed) 48
1
⁄16 122.1 48
1
⁄16 122.1 48
1
⁄16 122.1 42
1
⁄16 106.8 42
1
⁄16 106.8 42
1
⁄16 106.8
H. Depth Excl. Handles (closed) 25
1
⁄4 64.1 25
1
⁄4 64.1 25
1
⁄4 64.1 25
1
⁄4 64.1 25
1
⁄4 64.1 25
1
⁄4 64.1
I. Depth Incl. Handles (closed)
JS48S 26
5
⁄8 67.6 N/A 26
3
⁄8 67.0
††
JS48S 26
5
⁄8 67.2 N/A 26
3
⁄8 67.0
††
JS48P 27
1
⁄8 68.9 JS48P 27
1
⁄8 68.9
J. Depth (fresh food door 52
9
⁄16 133.5 52
9
⁄16 133.5 52
9
⁄16 133.5 48
3
⁄4 123.8 48
3
⁄4 123.8 48
3
⁄4 123.8
open 90°)
K. Width (doors open 90°,
JS48S 50
3
⁄4 128.9 N/A 50
1
⁄4 127.6
†††
JS42S 44
3
⁄4 113.7 N/A 44
1
⁄4 112.4
†††
including handles) JS48P 51
7
⁄8 131.8 JS42P 45
7
⁄8 116.5
†
1
1
⁄4” vertical adjustment for leveling and height adjustments.
††
Add 1”/2.5 cm to depth (I) for extended handle kit, if used, on framed model.
†††
Add 2”/5.08 cm to width (K) for extended handle kit, if used, on framed model.
INSTALLATION GUIDE – CUT-OUT DIMENSION SPECIFICATIONS
A
B
D
E
F
I
H
G
J
K
C
TOP VIEW
Important: Because of continuing product improvements, Jenn-Air reserves the right to change specifications without notice. Dimensional specifications are provided for
planning purposes only. For complete details see installation instructions packed with product before selecting cabinetry, making cutouts or beginning installation.
