JRVCS1
7
BODY CONTROL MODULE (BCM) CONNECTIONS
PIN NO. WIRE COLOR/SIZE DESCRIPTION
65 (10) FRONT JACKS (OUT)
66 (10) FRONT JACKS (OUT)
67 WHITE (10) ELECTRIC SLIDE 5 -12V (OUT)
68 PURPLE (10) ELECTRIC SLIDE 5 +12V (OUT)
69 WHITE (10) ELECTRIC SLIDE 4 -12V (OUT)
70 PURPLE (10) ELECTRIC SLIDE 4 +12V (OUT)
71 WHITE (10) ELECTRIC SLIDE 3 -12V (OUT)
72 PURPLE (10) ELECTRIC SLIDE 3 +12V (OUT)
73 WHITE (10) ELECTRIC SLIDE 2 -12V (OUT)
74 PURPLE (10) ELECTRIC SLIDE 2 +12V (OUT)
75 WHITE (10) ELECTRIC SLIDE 1 -12V (OUT)
76 PURPLE (10) ELECTRIC SLIDE 1 +12V (OUT)
77 BLACK (10) CHASSIE GROUND (IN)
78 YELLOW (14) AWNING +12V (IN)
79 PURPLE (10) ELECTRIC SLIDE +12V (IN)
80 RED (10) BCM +12V (IN)
SETUP MENU LIST
ITEM SELECTION
GENERATOR PROPANE OR GAS
