Adjustments
1. Adjusting switching point:
- Turn on transmitter and receiver, set function switch to the “Gear OUT” position.
- Set coding switch to position SP (Switching Point)
- Push (-) button.
- Set function switch to the “Gear IN” position.
- Push (+) button.
- Set coding switch to desired mode.
2. Adjusting gear valve servo end positions (G):
- Gear switch on the transmitter to the “Gear OUT” position.
- Coding switch to position G.
- Push buttons + or - so that the valve servo lowers the undercarriage.
- Gear switch on the transmitter to the “Gear IN” position.
- Push buttons + or - so that the valve servo raises the undercarriage.
- Coding switch to mode required, or to next adjustment.
3. Adjusting Gear door servo (D1-D3):
 Gear switch on the transmitter to the “Gear OUT” position.
 Coding switch to position D1.
 Push buttons + or - so that the Gear door 1 servo opens.
 Gear switch on transmitter to the “Gear IN” position.
 Push buttons + or - so that the Gear door 1 servo closes.
 Repeat procedure for Gear door 2 and 3 with the coding switch positions D2 and D3.
 Coding switch to mode required, or to next adjustment.
4. Adjusting delay time between Doors opening and Gear up or down (1 - 3Sec)
 Gear switch on the transmitter to the “Gear OUT” position.
 Coding switch to TIME G.
 One push on the buttons changes the delay time approx. 0.5 sec
 By toggling the gear switch on the transmitter and pushing the +/- buttons determine the right delay time.
 Coding switch to mode required, or to next adjustment.
5. Adjusting delay time between opening and closing Doors: (4 -13 Sec)
 Gear switch on the transmitter to the “Gear OUT” position.
 Coding switch to TIME D.
 One push on the buttons changes the delay time approx. 1 sec
 By toggling the gear switch on the transmitter and pushing the +/- buttons find out the right delay time.
 Coding switch to wanted mode, or to next adjustment.
6. Reset-function
 While turning on the receiver keep both push buttons pressed. This resets every value except the switching
point.
Note:
- By using the Jet-Tronics pneumatic valves it is recommended that one checks the function of the circuit
by using normal servos, to understand its operation more easily.
- Using Mode 3, D3 will be the door which stays open.
- When using new electronic components, always perform range check.
