7
Notes:
1: At 3 bar pressure
2: Although the primary coil pressure rating is 1.0Mpa (10 bar) the 2 port zone valve supplied with the cylinder
is only rated 0.86MPa (8.6 bar). If the cylinder is to be plumbed into a system delivering 1.0MPa (10 bar) a
suitable 2 port zone valve will have to be sourced.
3: Indirect cylinders tested in conformance with BS EN 12897:2016
120i
150i
170i
210i
250i
300i
Max direct kW rating 3 3 3 3 3 3
Immersion heat up times
(Btm immersion, 3kW)
139 167 179 208 252 294
Coil surface area (m²) 0.51
Coil heat up times
3
15l/min 33.1 30.4 43.0 45.1 52.8 68.7
30l/min 26.9 30.2 34.8 37.7 46.7 57.9
45/min 25.0 28.8 32.3 34.2 41.7 51.0
Coil rating (kW)
15l/min 13.1 16.2 13.7 14.3 14.8 13.0
30l/min 16.3 16.3 17.1 17.3 17.4 15.9
45l/min 17.6 17.7 18.8 19.1 19.0 17.5
Pressure drop through
coil
15l/min 0.04
30l/min 0.13
45l/min 0.31
Hot water capacity (volume to
>40°C)
126 145 171 187 228 256
Weight empty (kg) 31 34 37 42 46 53
Weight full (kg) ¹ 168 189 215 237 279 336
Volume (Litres)
1
137 155 178 195 233 283
Max mains pressure 1.6 kPa (16 Bar)
Max design/rated pressure 0.8 kPa (8 Bar)
Operating pressure/PRV set
pressure
0.3 kPa (3 Bar)
Max primary pressure
2
1.0 kPa (10 Bar)
Expansion relief valve setting 0.8 kPa (8 Bar)
T&P valve setting 90°C +/- 5°C/ 1.0 kPa (10 Bar)
T&P Part number 95 605 810
Immersion heater electrical
rating
3.0kW@240V/2.8kW@230V ~
Table 02: Performance
