GAS SYSTEM
Gas inlet connection: Flared ½” inlet and is located on the right hand
side of the gas grate.
Regulator: Beckley Type A.G.A. App. No. 4688(Nat gas only)
3/B BSP Female for LPG
Bromic Type BMWF1A A.G.A. App. No. 5149
Piping: 5/16” aluminium tube with flared fittings.
Thickness of pipework is 19 guage.
Gas control: A simplosit S.I.T. H-O.500.017 model (AGA
approval No. 3531) is located under the burner
tray.
Burner: A folded mild steel tray with deflector plate. A
cast iron venturi tapered mixing tube is welded to
the base through which gas is introduced.
Pilot: S.I.T. Pilot assembly OxypilotN.G.No.9418.Oxypilot
L.P.G.9603. ¼” B.S.P. connection. Thickness of pipe
is 19 guage ¼” aluminium.Pilot located on the right
hand side.
Pilot Turn off Value: Effibi mini valve A.G.A. No. 5301.
Pressure Test Point: ¼” diameter nipple located behind the outlet of the
gas valve.Inlet pressure is measured on outlet
point located on regulator.
Injector: Details – Section drawing.
