UHPX/UHPXi/UHPXD NOZZLES
UHPX
PART
NO.
UHPXi
PART NO.
UHPXD
PART NO.
ORIFICE
SIZE*
30,000 psi
(2,069 bar)
35,000 psi
(2,414 bar)
40,000 psi
(2,758 bar)
in mm gpm lpm gpm lpm gpm lpm
UHPX-036 UHPXi-036 UHPXD-036 0.036 0.91 4.5 17.0 4.9 18.4 5.2 19.6
UHPX-037 UHPXi-037 UHPXD-037 0.037 0.93 4.7 18.0 5.1 19.4 5.5 20.7
UHPX-038 UHPXi-038 UHPXD-038 0.038 0.96 5.0 18.9 5.4 20.5 5.8 21.9
UHPX-039 UHPXi-039 UHPXD-039 0.039 0.99 5.3 19.9 5.7 21.5 6.1 23.0
UHPX-040 UHPXi-040 UHPXD-040 0.040 1.02 5.5 21.0 6.0 22.7 6.4 24.2
UHPX-042 UHPXi-042 UHPXD-042 0.042 1.06 6.1 23.1 6.6 25.0 7.1 26.7
UHPX-046 UHPXi-046 UHPXD-046 0.046 1.16 7.3 27.7 7.9 30.0 8.5 32.0
UHPX-052 UHPXi-052 UHPXD-052 0.052 1.32 9.4 35.5 10.1 38.3 10.8 40.9
UHPX-067 UHPXi-067 UHPXD-067 0.067 1.70 15.6 58.9 16.8 63.6 18.0 68.0
* Orifice size is denoted in the part number (-018, etc.).
Flow rate in chart is per nozzle. Multiply flow by the number of nozzles being used to determine
the overall flow rate of the tool
