JETStream FXG2 Tornado Gun - Appendix C; Flow Charts

34 PI-120 March 2020
Appendix C
Flow Charts
UHPX/UHPXi/UHPXD NOZZLES
UHPX
PART
NO.
UHPXi
PART NO.
UHPXD
PART NO.
ORIFICE
SIZE*
30,000 psi
(2,069 bar)
35,000 psi
(2,414 bar)
40,000 psi
(2,758 bar)
in mm gpm lpm gpm lpm gpm lpm
UHPX-PLUG NOT APPLICABLE
UHPX-005 UHPXi-005 UHPXD-005 0.005 0.13 0.09 0.33 0.09 0.35 0.10 0.38
UHPX-006 UHPXi-006 UHPXD-006 0.006 0.15 0.12 0.47 0.13 0.51 0.14 0.55
UHPX-007 UHPXi-007 UHPXD-007 0.007 0.18 0.17 0.64 0.18 0.69 0.20 0.74
UHPX-008 UHPXi-008 UHPXD-008 0.008 0.20 0.22 0.84 0.24 0.91 0.26 1.0
UHPX-009 UHPXi-009 UHPXD-009 0.009 0.23 0.28 1.1 0.30 1.1 0.32 1.2
UHPX-010 UHPXi-010 UHPXD-010 0.010 0.25 0.35 1.3 0.37 1.4 0.40 1.5
UHPX-011 UHPXi-011 UHPXD-011 0.011 0.28 0.42 1.6 0.45 1.7 0.48 1.8
UHPX-012 UHPXi-012 UHPXD-012 0.012 0.30 0.50 1.9 0.54 2.0 0.58 2.2
UHPX-013 UHPXi-013 UHPXD-013 0.013 0.33 0.59 2.2 0.63 2.4 0.68 2.6
UHPX-014 UHPXi-014 UHPXD-014 0.014 0.36 0.68 2.6 0.73 2.8 0.78 3.0
UHPX-015 UHPXi-015 UHPXD-015 0.015 0.38 0.78 3.0 0.80 3.2 0.90 3.4
UHPX-016 UHPXi-016 UHPXD-016 0.016 0.41 0.89 3.4 1.0 3.6 1.0 3.9
UHPX-017 UHPXi-017 UHPXD-017 0.017 0.43 1.0 3.8 1.1 4.1 1.2 4.4
UHPX-018 UHPXi-018 UHPXD-018 0.018 0.46 1.1 4.2 1.2 4.6 1.3 4.9
UHPX-019
UHPXi-019 UHPXD-019
0.019 0.48 1.3 4.7 1.4 5.1 1.4 5.5
UHPX-020 UHPXi-020 UHPXD-020 0.020 0.51 1.4 5.2 1.5 5.7 1.6 6.1
UHPX-021 UHPXi-021 UHPXD-021 0.021 0.53 1.5 5.8 1.7 6.2 1.8 6.7
UHPX-022 UHPXi-022 UHPXD-022 0.022 0.56 1.7 6.3 1.8 6.9 1.9 7.3
UHPX-023
UHPXi-023 UHPXD-023
0.023 0.58 1.8 6.9 2.0 7.5 2.1 8.0
UHPX-024 UHPXi-024 UHPXD-024 0.024 0.61 2.0 7.3 2.2 8.2 2.3 8.7
UHPX-025 UHPXi-025 UHPXD-025 0.025 0.64 2.2 8.2 2.3 8.9 2.5 9.5
UHPX-026 UHPXi-026 UHPXD-026 0.026 0.66 2.3 8.9 2.5 9.6 2.7 10.2
UHPX-027 UHPXi-027 UHPXD-027 0.027 0.68 2.5 9.6 2.7 10.3 2.9 11.0
UHPX-028 UHPXi-028 UHPXD-028 0.028 0.71 2.7 10.3 2.9 11.1 3.1 11.9
UHPX-029 UHPXi-029 UHPXD-029 0.029 0.73 2.9 11.0 3.2 11.9 3.4 12.7
UHPX-030 UHPXi-030 UHPXD-030 0.030 0.76 3.1 11.8 3.4 12.8 3.6 13.6
UHPX-031 UHPXi-031 UHPXD-031 0.031 0.78 3.3 12.6 3.6 13.6 3.8 14.6
UHPX-032 UHPXi-032 UHPXD-032 0.032 0.81 3.6 13.4 3.8 14.5 4.1 15.5
UHPX-033 UHPXi-033 UHPXD-033 0.033 0.83 3.8 14.3 4.1 15.4 4.4 16.5
UHPX-034 UHPXi-034 UHPXD-034 0.034 0.86 4.0 15.2 4.3 16.4 4.6 17.5
UHPX-035 UHPXi-035 UHPXD-035 0.035 0.89 4.2 16.1 4.6 17.4 4.9 18.6
* Orifice size is denoted in the part number (-018, etc.).
Flow rate in chart is per nozzle. Multiply flow by the number of nozzles being used to determine
the overall flow rate of the tool
