Hardware Installation
Caution:
Static electricity around the antenna can damage your Radarcape
or Internet router if there is no ground connection!
Do NOT mount the antenna on isolated ground, e.g. wooden
stick or plastic or without any connection to ground!
THE ANTENNA MUST BE GROUNDED!
Radarcape
Router
Mast Pole / Antenna Mouting Point
Mode-S antenna
network
cable
Router providing
DHCP service
antenna
cable
GPS
antenna
power
supply
power
outlet
Caution:
Static electricity around the antenna can damage your Radarcape
or Internet router if there is no ground connection!
Do NOT mount the antenna on isolated ground e.g. wooden stick or plastic
or without any connection to ground!
IMPORTANT!
conductive
connection
to ground
PC
